Warranty: 1 Year

Model: YJPI Series

Protection Class: IP68

Operating Noise: <65dB

Customization: Available

Connector Model: DT06-2S

Hydrogen Leakage: <0PPM

Working Frequency: 1–30HZ

Medium Temperature: –40℃–120℃

Control Mode: PEAK-HOLD Control

Interface Size: Standard/Customizable

Solenoid Valve Structure: Normally Closed

Flow Aperture & Cv Value:1.45mm aperture & 0.06 / 2mm aperture & 0.116

Flowing Media: Hydrogen, Nitrogen, Oxygen, Natural Gas, Air, Water, Methanol, Liquid Ammonia, etc.

Operating Pressure:0–30barG @24V voltage platform (18–32VDC range) / 0–30barG @12V voltage platform (8–16VDC range)

Opening Response Time:6±1ms @coil resistance 8.8Ω, PEAK current 2A, HOLD current 0.6A / 1±0.2ms @coil resistance 1.8Ω, PEAK current 6.5A, HOLD current 2A
