Warranty: 1 Year

Inrush Current: 3A

Model: YJDV Series

Coil Resistance: 35Ω

PTC Peak Power: 54W

Rated Voltage: 24VDC

Customization: Available

Voltage Range: 18–32VDC

Insulation Resistance: >20MΩ

Operating Pressure: <500kPaA

Opening Response Time: 10±2ms

NTC Output Range: 0.07kΩ–45kΩ

Maximum PTC Temperature: 150℃

Ambient Temperature: –40℃–120℃

Medium Temperature: –40℃–120℃

Interface Size: Standard/Customizable

Solenoid Valve Structure: Normally Closed

Operation Mode: Open on Power, Close on Power Off

Flowing Media: Water, Hydrogen, Nitrogen, Methanol, Ammonia, etc.

Flow Aperture & Cv Value:2.5mm aperture & 0.18 / 3.5mm aperture & 0.35

Applications:Fuel Cells, Hydrogen Internal Combustion Engines, Petrochemical Industry, Laboratories, Hydrogen Refueling Stations
