Hydrogen Production Valve
Customizable Design
Protection Class: IP68
Voltage Range: 24VDC
Connector Model: DT06-2S
Operating Pressure: <50bar
On-Off Solenoid Valve Structure
Coil Options: Standard Coil / Explosion-Proof Coil
Working Frequency Range: ≤30HZ (Recommended: 5HZ)
Application: Strong Alkali Environments (e.g., KOH Solution)
Applicable to: 0.5/1/2/5 Nm³/h Hydrogen Production Systems
PEAK-HOLD Control:PEAK Current: 2±0.2A / HOLD Current: 0.7±0.1A
Optional Accessories: Isolation Valves, Safety Valves, Pressure Sensors
Protection Class: IP68
Voltage Range: 24VDC
Connector Model: DT06-2S
Operating Pressure: <50bar
On-Off Solenoid Valve Structure
Coil Options: Standard Coil / Explosion-Proof Coil
Working Frequency Range: ≤30HZ (Recommended: 5HZ)
Application: Strong Alkali Environments (e.g., KOH Solution)
Applicable to: 0.5/1/2/5 Nm³/h Hydrogen Production Systems
PEAK-HOLD Control:PEAK Current: 2±0.2A / HOLD Current: 0.7±0.1A
Optional Accessories: Isolation Valves, Safety Valves, Pressure Sensors
